5A02 5052 H32 H112 aluminum coil stock

Author:frank  Time:2019-08-02    Source:未知

5A02 5052 H32 H112 aluminum coil stock

Factory:

Specification:

Quantity:

Product Detail


5A02 5052 Aluminum coil is Al-Mg rust-proof aluminum alloy, which cannot be heat treated and strengthened. The alloy has a low magnesium content, a high plasticity, a good shape, and a low strength, but is stronger than the 3A21 alloy aluminum plate. Cold deformation can increase its strength while plasticity decreases. The alloy has good corrosion resistance and is suitable for use in marine environments. The alloy has good weldability. The machinability is poor in the annealing state, and the semi-cold hardening state can improve the machinability.

5052 Aluminum coil stock data sheet


Alloy Temper Thickness(mm) Width(mm) Length(mm) Application
5A02 5052 aluminum coil stock O、H24、H32、H34、H112 0.15-0.5 300-1600 800-6000 Ship structure, fuel tank, gasoline and lube conduit, flanges, etc.

Chonioal composition

Alloy  Si  Fe Cu Mn  Mg  Cr  Zn  Ti  Others Al
Every Total
5A02 0.4 0.4 0.1 0.15-0.4 2.0-2.8     0.15 0.05 0.15

Mechanical properties


Aluminium alloy & temper

Rm/Mpa
Tensile Strength

Rp0.2/Mpa
Proof Strength
A/%
Percentage elongation after fracture

HB
Hardness
5A02 5052-H32 210-260 130 5 61

Typical applications

      5A02 5052 aluminum alloy coil  is suitable for welded structures and containers with high process plasticity requirements and good corrosion resistance, such as fuel tanks, gasoline and lubricant pipes, nails, flanges, and lightly loaded parts, interior trim parts for ships and vehicles, etc. The wire is used as a rivet or electrode.
