4043A Aluminium Coil Strip
4043 Aluminium Strip Sizes / 4043 Aluminium Strip Suppliers in China
Brief introduction:
Brief introduction:
4xxx series aluminum representative for 4032 4043 4xxx series of aluminum belongs to the content of silicon high series. Usually silicon content in 4.5-6.0% between. Of building materials, machinery parts, forging materials, welding materials; Low melting point, corrosion resistance good product description: has the characteristics of heat, wear-resisting.
At present, the main products, 4043A aluminium coil strip, Carbon Steel, Stainless Steel, Corten Steel, Low Alloy Steel, Ship-Building Steel, Boiler and Pressure Vessel Steel, High Strength Steel, Bridge Steel, Anti-Seismic Steel, Z15/Z25/Z35 Tearing Resistance Steel, Wear-Resistant Steel, and Weathering Resistant Steel, etc., are certificated by the international authoritative organization. In addition, our ship steel plate has been recognized by the nine countries Classification Society including LR, GL, DNV, BV, NK, ABS, CCS, KR and RINA. Our 4043 Aluminium coil strip products have the core competitive advantages in the international market and have been exported to India, Vietnam, Pakistan, Singapore, Italy, Georgia, and Bangladesh etc.
Chemical Properties - 4043A Aluminium Coil Strip
| Alloy Designation | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Ga | V | Remarks | Others |
Aluminium min |
||
| Numerical | Chemical Sympols | Each | Total | |||||||||||||
|
EN AW -4043A |
EN AW- AI Si5(A) |
4.5-6.0 | 0.6 | 0.3 | 0.15 | 0.20 | - | - | 0.10 | 0.15 | - | - | - | 0.05 | 0.15 | Remainder |
Specification and Application - 4043A Aluminium Coil Strip
| Alloy No. | Thickness(mm) | Width(mm) | Temper |
| 4032 | 0.3~150 | 500~1650 | O,H12,H22,H14,H24,H16,H26,H28 |
| 4043 | 0.1~100 | 200~1950 | O-H112 |
| Application | Generally used in industrial, construction, plastic and curtain wall. Parts of electronic goods, automobile, components, decoration | ||
| Standard | GB/T 3880-2006 | ||
Physical Properties - 4043A Aluminium Coil Strip
The physical properties of aluminium / aluminum 4043 alloy are outlined in the following table.
| Properties | Metric | Imperial |
| Density | 2.69 g/cm3 | 0.0972 lb/in3 |
Mechanical Properties - 4043A Aluminium Coil Strip
The mechanical properties of aluminium / aluminum 4043 alloy are tabulated below.
| Properties | Metric | Imperial |
| Tensile strength | 145 MPa | 21000 psi |
| Yield strength (@diameter 12.7 mm/0.500 in) | 70 MPa | 10200 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break (@diameter 12.7 mm/0.500 in) | 22% | 22% |
| Shear strength | 90 MPa | 13100 psi |
| Hardness, Brinell (@load 500 kg; thickness 10.0 mm/1100 lb) | 39 | 39 |
Thermal Properties - 4043A Aluminium Coil Strip
The thermal properties of aluminium / aluminum 4043 alloy are tabulated below.
| Properties | Metric | Imperial |
| Thermal expansion co-efficient (average over 20-100°C/68-212°F) | 22.1 µm/m°C | 12.3 µin/in°F |
| Thermal conductivity | 163 W/mK | 1130 BTU in/hr.ft².°F |
Specifications - 4043A Aluminium Coil Strip
with best quality and price
superior quality of raw material
reasonable and stable chemical composition
